KNX Wall Mount Outdoor Microwave Sensor contains four independent logic blocks and one combined logic block. Supported input logical conditions include: Microwave sensing status, brightness value, temperature value, dry contact status and external telegram. The sensor can control lighting, curtain and threshold value.

• The sensor can be set to automatic or semi-automatic mode.
• The logic validity can be set through external telegram input.
• 2 dry contact input interfaces can wok as dry contact or LED indicators. The control types of dry contact targetoutput can be set as switch, dimming and scene.
• 2 working modes: Single mode and Master & Slave mode.
• 2 logical relations: AND, OR
• 5 logical condition sources: Microwave sensing status, brightness value, temperature value, dry contact statusand external telegram.
• Control types: Switch control, Absolute dimming control, Curtain control, Alarm control, Percentage control , Sequence control, Scene control, String(14 bytes) control, Logic combination control.
• 5 logic blocks with 10 target output for each and supports dry contacts and external telegram locking/unlocking, ordelay unlocking. Telegram locking/unlocking can be set to send on/off telegram.
• With 2CH constant brightness control function, the sensor supports 4 preset constant values and forced operationdimming.

Basic Parameters

• Working voltage 21~30V DC
• Working current 20mA/30V DC
• Communication KNX
• Cable diameter of KNX terminal 0.6 - 0.8mm
• Microwave detection range Φ28m (Installation height:3m)
• Temperature detection range -30°C~70°C
• Humidity detection range 20~95％RH
• Brightness detection range 0~35000LUX

External Environment

• Working temperature -5℃~45℃
• Working relative humidity ≤90%
• Storage temperature -20℃~60℃
• Storage relative humidity ≤93%

Specifications

• Dimensions 126×78×114(mm)
• Net weight 360g
• Housing material: ASA, stainless steel
• Installation: Wall mount
• Protection rating (Compliant with EN 60529): IP54
